CATALOGUE/STOCKAGE BATTERIE/RÉF 11994
60kWh HV LiFePO4 Battery System Deye IP20 — view 1
60kWh HV LiFePO4 Battery System Deye IP20 — view 2
60kWh HV LiFePO4 Battery System Deye IP20 — view 3
60kWh HV LiFePO4 Battery System Deye IP20 — view 4
V-TAC · SKU 11994
● BAJO PEDIDO · CONSULTAR DISPONIBILIDAD

60kWh HV LiFePO4 Battery System Deye IP20

V-TAC catalog SKU supplied on request. Full electrical specification is in the manufacturer datasheet below — request price and availability and we confirm from the V-TAC feed before quoting.

Prix / disponibilité sur demande
SUR COMMANDE · PAS DE PRIX CATALOGUE PUBLIÉ
GARANTIE
Warranty Conditions
CERTIFICATION
CEI 0-21

Spécifications techniques

Manual
CEI 0-21
CEI 0-16
IEC 62619
Warranty Conditions
EMC License
Expansion and Use Statement
General Information
Electrical Data
Current Maximum Charging Current100A; Maximum Discharge Current: 125A; Standard Charging Current: 50A; Standard Discharge Current: 50A;
Wattage 61.44kWh (5.12 kWh x 12)
Voltage Nominal Voltage614.4V; Charging Voltage: 499.2 - 700V;
Body Details
Mount On a Rack
Capabilities
Battery Capacity 100Ah LFP (LiFePO4)
Working conditions ` -20 +55°C
IP Rating IP20
Cells Chemistry LiFePO4
Dimensions
Size 589x590x2240 mm
Product Data
Order code 11994
Additional
Release Date 25.09.2024
Warranty 10 years
Brand Deye
