10.24kWh LiFePO4 Battery Grey IP65 — view 5
V-TAC · VT-12040-1
● BAJO PEDIDO · CONSULTAR DISPONIBILIDAD

10.24kWh LiFePO4 Battery Grey IP65

V-TAC catalog SKU supplied on request. Full electrical specification is in the manufacturer datasheet below — request price and availability and we confirm from the V-TAC feed before quoting.

Consultar precio / disponibilidad
BAJO PEDIDO · SIN PRECIO DE TARIFA PUBLICADO
WARRANTY
Warranty Conditions
CERTIFICATION
IEC 62619

Technical specification

Manual
Warranty Conditions
IEC 62619
CEI 0-21 | | | | |
ЕМС Report
RED
General Information
Electrical Data
Current Charge/Discharge Current90A; Max. Continuous Charge/Discharge Current: 100A;
Wattage 10.24kWh
Voltage Nominal Voltage51.2V; Standard Charge Voltage: 57.6V; Upper limit Charging Voltage: 57.6V; End-of-discharge Voltage: 43.2V;
Body Details
Mount Floor Mounting
Capabilities
IP Rating IP65
Cells Chemistry LiFePO4
Battery Capacity 200Ah
Working conditions Charge temperature Range (°C)0 ~ 60; Discharge temperature Range (°C): -20 ~ 60;
Dimensions
Size 460 x 265 x 800mm
Product Data
Order code 12715
Product code VT-12040-1
Item Weight 95.8 kg
EAN Code 3800170260658
Additional
Release Date 24.03.26
Brand V-TAC
Warranty 10 years
Additional information Charge the battery at constant current 90A until voltage reaches 58.4V, then charge at constant voltage 58.4V till charge current is 10.3A

Documents

PDFDeye-Declaration-of-Conformity-IT-VTAC.pdfV-TAC · datasheetPDFDeye_Self Declaration of Conformity_IT_VTAC.pdfV-TAC · datasheetPDFDichiarazione_di_conformità_CEI0-21 SOLIS S6-EH3P(8-15)K02-NV-YD-L(4).pdfV-TAC · datasheetPDFNing_Sun-(3.6-10)_VT-12040-1&10240_CEI_021 2022-03 _ita_eng_25-212-00.pdfV-TAC · datasheetPDFNing_Sun-3-12K_VT-12040-1&VT-10240W&VT-10240B_GCC_CEI_021_ita_25-432-00.pdfV-TAC · datasheetPDFNing_Sun-3-6K_VT-12040-1_GCC_CEI_021_ita_24-422-00.pdfV-TAC · datasheetPDFVT-12040-1-SKU-11447-1-CB-IEC-62619.pdfV-TAC · datasheetPDFVT-12040-1-SKU-11447-1-EMC-Report.pdfV-TAC · datasheetPDFVT-12040-1-SKU-11447-1-RED-2014-53-EU.pdfV-TAC · datasheetPDFVT-12040-1-SKU-12715-Technical-Specs-v1.pdfV-TAC · datasheetPDFVT-12040-1-SKU-12715-Warranty-Card.pdfV-TAC · datasheetPDFVT-12040-1-SKU-12715-Manual-insturctions.pdfV-TAC · external
