CATÁLOGO/INVERSORES HÍBRIDOS/REF 12224
SOLIS 10kW Hybrid Solar Inverter Three Phase High Voltage — view 1
SOLIS 10kW Hybrid Solar Inverter Three Phase High Voltage — view 2
SOLIS 10kW Hybrid Solar Inverter Three Phase High Voltage — view 3
SOLIS 10kW Hybrid Solar Inverter Three Phase High Voltage — view 4
SOLIS 10kW Hybrid Solar Inverter Three Phase High Voltage — view 5
SOLIS 10kW Hybrid Solar Inverter Three Phase High Voltage — view 6
SOLIS 10kW Hybrid Solar Inverter Three Phase High Voltage — view 7
SOLIS 10kW Hybrid Solar Inverter Three Phase High Voltage — view 8
V-TAC · S6-EH3P10K2-H
● STOCK LIMITADO · ALMACÉN ENTREGA

SOLIS 10kW Hybrid Solar Inverter Three Phase High Voltage

10kW Hybrid Solar Inverter Three Phase High Voltage with IP66 protection and an operating range of -25 ~ +60°C. 10 years; certification on file: EMC License and LVD License.

desde€1,298IVA EXCL. · PRECIO DE TARIFA
NivelTu precioCondiciones
Trade€1,298Card · PayPal · Klarna · Apple Pay
Pro€1,233Card · PayPal · Klarna · Apple Pay
Master€1,168Card · PayPal · Klarna · Apple Pay
Abre una cuenta para pedir
GARANTÍA DEL FABRICANTE
10 years
Se aplican las condiciones propias del fabricante. Nosotros tramitamos la reclamación — consulta las condiciones de venta.
CERTIFICACIÓN · 2
EMC LicenseLVD License

Especificaciones técnicas

ELECTRICAL DATA13 items
Max. input current16A / 16A Max. short circuit current: 24A / 24A
Max. output current15.2A / 14.4A
Rated grid output current15.2A / 14.4A
Max. usable PV input power16kW
Max. charge / discharge power10kW
Rated output power AC10kW
Max. PV Input DC Voltage1000V
MPPT Range200~850V
Rated PV Input DC Voltage600V
Start-up Voltage160V
Rated grid frequency50 Hz / 60 Hz
Power Factor>0.99 (0.8 leading - 0.8 lagging)
PhaseThree Phase
PHYSICAL DATA3 items
Working conditions-25 ~ +60°C
IP RatingIP66
Size600 x 500 x 230 mm
CERTIFICATIONS & WARRANTY1 item
Warranty10 years
PACKAGING2 items
Items per pack1
Item Weight30.2 kg
PRODUCT DATA4 items
Order code12224
Product codeS6-EH3P10K2-H
Release Date31.10.2024
BrandSOLIS
