15kW Hybrid Solar Inverter Three Phase Low Voltage Black 10yrs Warranty

V-TAC catalog SKU supplied on request. Full electrical specification is in the manufacturer datasheet below — request price and availability and we confirm from the V-TAC feed before quoting.

Consultar precio / disponibilidad

BAJO PEDIDO · SIN PRECIO DE TARIFA PUBLICADO

Solicitar precio y disponibilidad

WARRANTY

Warranty Conditions

CERTIFICATION

CEI 0-21

Technical specification

Manual

Declaration of Conformity |

EMC License

LVD License

CEI 0-21

EN 50549

Warranty Conditions

Electrical Data

Current Max. Operating PV Input Current (A)36+36; Max. Input Short-Circuit Current (A): 54+54; Rated AC Input/Output Current (A): 22.8/21.8; Max. AC Input/Output Current (A): 25/24 Max. Continuous AC Passthrough: 70A;

Wattage Max. PV Input Power (W)24000; Max. PV Access Power (W): 30000; Rated AC Input/Output Active Power: 15000; Max. AC Input/Output Apparent Power (VA) 16500; Peak Power (off-grid) (W): 2 times of rated power, 10s

Voltage Rated PV Input Voltage550V; MPPT Range: 160-650V; Rated Input/Output Voltage/Range (V) 220/380V, 230/400V 0.85Un-1.1Un; Start-up Voltage: 160V;

Frequency Rated Input/Output Grid Frequency/Range(Hz) 50/45-55, 60/55-65

Power Factor 0.8 leading to 0.8 lagging

Phase Three Phase

Capabilities

Working conditions -40 to +60℃, >45℃ Derating

IP Rating IP65

Dimensions

Size 456 × 750 × 268.5 mm (Excluding Connectors and Brackets)

Product Data

Order code 121841

Product code SUN-15K-SG05LP3-EU-SM2

Items per pack 1

Item Weight 50.6 kg

Certificates & Standards

Certification IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002,OVE-Richtlinie R25, G99, VDE-AR-N 4105

Additional

Release Date 07.01.2025

Warranty 10 years

Additional information Battery TypeLead-acid or Lithium-ion Battery Voltage Range (V): 40-60 Max. Charging Current (A): 280 Max. Discharging Current (A): 280 Charging Strategy for Li-ion Battery: Self-adaption to BMS Number of Battery Input: 1 Grid Connection Form: 3L+N+PE Type of Cooling: Intelligent Air Cooling Max. Efficiency: 97.6% MPPT Efficiency: >99% Euro Efficiency: 97.0%

Brand Deye
