CATÁLOGO/INVERSORES HÍBRIDOS/REF 12184
15kW Hybrid Solar Inverter Three Phase Low Voltage SUN-15K-SG05LP3 — view 1
15kW Hybrid Solar Inverter Three Phase Low Voltage SUN-15K-SG05LP3 — view 2
15kW Hybrid Solar Inverter Three Phase Low Voltage SUN-15K-SG05LP3 — view 3
15kW Hybrid Solar Inverter Three Phase Low Voltage SUN-15K-SG05LP3 — view 4
V-TAC · SUN-15K-SG05LP3-EU-SM2
● BAJO PEDIDO · CONSULTAR DISPONIBILIDAD

15kW Hybrid Solar Inverter Three Phase Low Voltage SUN-15K-SG05LP3

15kW Hybrid Solar Inverter Three Phase Low Voltage with IP65 protection and an operating range of -40 to +60℃, >45℃ Derating. 10 years; certification on file: Declaration of Conformity, Certificate of Conformity, EMC License and LVD License.

desde€1,938IVA EXCL. · PRECIO DE TARIFA
NivelTu precioCondiciones
Trade€1,938Card · PayPal · Klarna · Apple Pay
Pro€1,841Card · PayPal · Klarna · Apple Pay
Master€1,744Card · PayPal · Klarna · Apple Pay
Solicitar precio y disponibilidad
GARANTÍA DEL FABRICANTE
10 years
Se aplican las condiciones propias del fabricante. Nosotros tramitamos la reclamación — consulta las condiciones de venta.
CERTIFICACIÓN · 4
Declaration of ConformityCertificate of ConformityEMC LicenseLVD License

Especificaciones técnicas

ELECTRICAL DATA15 items
Max. Operating PV Input Current (A)36+36
Max. Input Short-Circuit Current (A)54+54
Rated AC Input/Output Current (A)22.8/21.8
Max. AC Input/Output Current (A)25/24 Max. Continuous AC Passthrough: 70A
Max. PV Input Power (W)24000
Max. PV Access Power (W)30000
Rated AC Input/Output Active Power15000
Peak Power (off-grid) (W)2 times of rated power, 10s
Rated PV Input Voltage550V
MPPT Range160-650V
Start-up Voltage160V
FrequencyRated Input/Output Grid Frequency/Range(Hz) 50/45-55, 60/55-65
Power Factor0.8 leading to 0.8 lagging
PhaseThree Phase
Additional information Battery TypeLead-acid or Lithium-ion Battery Voltage Range (V): 40-60 Max. Charging Current (A): 280 Max. Discharging Current (A): 280 Charging Strategy for Li-ion Battery: Self-adaption to BMS Number of Battery Input: 1 Grid Connection Form: 3L+N+PE Type of Cooling: Intelligent Air Cooling Max. Efficiency: 97.6% MPPT Efficiency: >99% Euro Efficiency: 97.0%
PHYSICAL DATA3 items
Working conditions-40 to +60℃, >45℃ Derating
IP RatingIP65
Size456×750×268.5 mm (Excluding Connectors and Brackets)
CERTIFICATIONS & WARRANTY2 items
CertificationIEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002,OVE-Richtlinie R25, G99, VDE-AR-N 4105
Warranty10 years
PACKAGING2 items
Item Weight50.6 kg
Items per box1
PRODUCT DATA4 items
Order code12184
Product codeSUN-15K-SG05LP3-EU-SM2
Release Date29.08.2024
BrandDeye
