8kW On/Off Grid Hybrid Solar Inverter Three Phase 3 yrs Warranty IP65

V-TAC catalog SKU supplied on request. Full electrical specification is in the manufacturer datasheet below — request price and availability and we confirm from the V-TAC feed before quoting.

Consultar precio / disponibilidad

BAJO PEDIDO · SIN PRECIO DE TARIFA PUBLICADO

Solicitar precio y disponibilidad

WARRANTY

Warranty Conditions |

CERTIFICATION

EN 50549

Technical specification

Manual

ЕМС Report

EMC License

LVD License

LVD Report

EN 50549

Warranty Conditions |

General Information

Electrical Data

Current Max. Current per MPPT (Input PV)12A Max. Output Current (AC): 12.7A

Wattage Max. Input Power10.4kW; Rated AC Power: 8.8kW;

Voltage Max. PV Input Voltage1000V; Rated Voltage AC: 400V, 3W + N + PE; MPP Range Input (PV): 180V-850V;

Frequency Rated Grid Frequency 50Hz / 60Hz

Power Factor 0.8 lagging~0.8 leading

Phase Three Phase

Capabilities

Working conditions -25°C to +60°C

IP Rating IP65

Dimensions

Size 530 × 600 × 200 mm

Product Data

Order code 11375

Product code VT-6608303

Item Weight 29kg

Additional

Release Date 15.09.2022

Warranty 10 years

Brand INVT

Documents

PDF11375-EN-50549-VT-6608303.pdfV-TAC · datasheet PDFVT-6608303-EMC-License.pdfV-TAC · datasheet PDFVT-6608303-EMC-Report.pdfV-TAC · datasheet PDFVT-6608303-Inverter-On-Off-spec-sheets.pdfV-TAC · datasheet PDFVT-6608303-LVD-License.pdfV-TAC · datasheet PDFVT-6608303-LVD-Report.pdfV-TAC · datasheet PDFWarranty-Card-V-TAC-INVT-Inverters.pdfV-TAC · datasheet PDFWarranty-Terms-And-Conditions-Inverters-INVT.pdfV-TAC · datasheet PDFVT-6608303-instructions.pdfV-TAC · external
