CATÁLOGO/INVERSORES HÍBRIDOS/REF 11374
INVT 3.6kW On/Off Grid Hybrid Solar Inverter Single Phase — view 1
INVT 3.6kW On/Off Grid Hybrid Solar Inverter Single Phase — view 2
INVT 3.6kW On/Off Grid Hybrid Solar Inverter Single Phase — view 3
V-TAC · VT-66036103
● EN STOCK · ALMACÉN ENTREGA

INVT 3.6kW On/Off Grid Hybrid Solar Inverter Single Phase

3.6kW On/Off Grid Hybrid Solar Inverter Single Phase with IP65 protection and an operating range of -25°C to +60°C. 10 years; certification on file: EMC License and LVD License.

desde€579IVA EXCL. · PRECIO DE TARIFA
NivelTu precioCondiciones
Trade€579Card · PayPal · Klarna · Apple Pay
Pro€550Card · PayPal · Klarna · Apple Pay
Master€521Card · PayPal · Klarna · Apple Pay
Abre una cuenta para pedir
GARANTÍA DEL FABRICANTE
10 years
Se aplican las condiciones propias del fabricante. Nosotros tramitamos la reclamación — consulta las condiciones de venta.
CERTIFICACIÓN · 2
EMC LicenseLVD License

Especificaciones técnicas

ELECTRICAL DATA9 items
Max. PV Input Current12A Max. Output Current: 16A
Max. Input Power4.6kW
Rated AC Power3.6kW
MPPT Range (PV)125-500V
Rated Voltage (AC)230V, L + N + PE
Operating Voltage Range (AC)176- 270V
Frequency50Hz / 60Hz
Power Factor0.8 lagging~0.8 leading
PhaseSingle Phase
MECHANICAL & BUILD1 item
Max. Input (PV)550V
PHYSICAL DATA3 items
Working conditions-25°C to +60°C
IP RatingIP65
Size550 x 515 x 200 mm
CERTIFICATIONS & WARRANTY1 item
Warranty10 years
PACKAGING1 item
Item Weight25kg
PRODUCT DATA4 items
Order code11374
Product codeVT-66036103
Release Date15.09.2022
BrandINVT
