KATALOG/HYBRID-WECHSELRICHTER/ART.-NR. 12185
20kW Hybrid Solar Inverter Three Phase Low Voltage — view 1
20kW Hybrid Solar Inverter Three Phase Low Voltage — view 2
20kW Hybrid Solar Inverter Three Phase Low Voltage — view 3
20kW Hybrid Solar Inverter Three Phase Low Voltage — view 4
V-TAC · SUN-20K-SG05LP3-EU-SM2
● AUF ANFRAGE · VERFÜGBARKEIT ANFRAGEN

20kW Hybrid Solar Inverter Three Phase Low Voltage

20kW Hybrid Solar Inverter Three Phase Low Voltage with IP65 protection and an operating range of -40 to +60℃, >45℃ Derating. 10 years; certification on file: Declaration of Conformity, Certificate of Conformity, EMC License and LVD License.

ab€2,535EXKL. UST. · LISTENPREIS
StufeIhr PreisZahlungsziel
Trade€2,535Card · PayPal · Klarna · Apple Pay
Pro€2,408Card · PayPal · Klarna · Apple Pay
Master€2,282Card · PayPal · Klarna · Apple Pay
HERSTELLERGARANTIE
10 years
Es gelten die eigenen Bedingungen des Herstellers. Wir bearbeiten die Reklamation — siehe Verkaufsbedingungen.
ZERTIFIZIERUNG · 4
Declaration of ConformityCertificate of ConformityEMC LicenseLVD License

Technische Daten

ELECTRICAL DATA14 items
Max. Operating PV Input Current (A)36+36
Max. Input Short-Circuit Current (A)54+54
Rated AC Input/Output Current (A)30.4/29
Max. AC Input/Output Current (A)33.4/31.9 Max. Continuous AC Passthrough: 70A
Max. DC Input Power (W)32000 Max. PV Access Power (W): 30000
Rated AC Input/Output Active Power20000W
Peak Power (off-grid) (W)2 times of rated power, 10s
Rated PV Input Voltage550V
MPPT Range160-650V
Start-up Voltage160V
FrequencyRated Input/Output Grid Frequency/Range(Hz) 50/45-55, 60/55-65
Power Factor0.8 leading to 0.8 lagging
PhaseThree Phase
Additional information Battery TypeLead-acid or Lithium-ion Battery Voltage Range (V): 40-60 Max. Charging Current (A): 350 Max. Discharging Current (A): 350 Charging Strategy for Li-ion Battery: Self-adaption to BMS Number of Battery Input: 1 Grid Connection Form: 3L+N+PE Type of Cooling: Intelligent Air Cooling Max. Efficiency: 97.6% MPPT Efficiency: >99% Euro Efficiency: 97.0%
PHYSICAL DATA3 items
Working conditions-40 to +60℃, >45℃ Derating
IP RatingIP65
Size456×750×268.5 mm (Excluding Connectors and Brackets)
CERTIFICATIONS & WARRANTY2 items
CertificationIEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002,OVE-Richtlinie R25, G99, VDE-AR-N 4105
Warranty10 years
PACKAGING2 items
Item Weight50.6 kg
Items per box1
PRODUCT DATA4 items
Order code12185
Product codeSUN-20K-SG05LP3-EU-SM2
Release Date29.08.2024
BrandDeye

Dokumente
